Gearbox Oil

View products

EA Lubricant Oil is a top gear oil company that can offer you a wide range of industrial gearbox oils and premium quality service. To guarantee the flawless running of your gearbox, our industrial gearbox oils are made with the newest additions and formulations, and excel as per global quality standards. Our clientele consists of over 10K users and more than 200 corporations across the globe. All of these factors say more than enough about our performance as an industrial gear oil manufacturing company.

As an industrial gear oil company, Gandhar offers several varied products under industrial gearbox oils. Specifications of these products include:



\ View more
Product
Synthetic Industrial Gear BRS H
Base fluid
Sythetic
Viscosity grade
220, 320, 460, 680, 1000,
Description

EA BRS H synthetic gear oils are range of products particularly suited to gear applications in which extreme conditions are expected. These products are formulated with synthetic base stocks in order to provide performance greatly superior to conventional petroleum oils. Applications Dragline, shovel and heavy process gear cases Planetary transmissions Electric wheel motors Compliances: U.S. Steel 224, AGMA 9005-E02, DIN 51517 Part 3

Product
EA Gear & Transmisson Oil
Base fluid
Mineral base
Viscosity grade
Description

EA HD is a mineral transmission oil. The product is suitable for use in manual transmissions and other transmissions in classic vehicles that require a medium single-grade oil with extreme pressure protection that meets the API GL-5 specification.

Product
Gear Oils XD
Base fluid
Mineral base
Viscosity grade
100, 150, 220, 320, 460, 680,
Description

Gear Oils XD is a range of oil blends specially formulated for the lubrication of spur, helical, bevel gear and bearing in industrial equipment, as well as ships with heavy load and impact load under harsh environment and weather conditions. These oils are recommended for applications that require long service life, get little maintenance or have a very difficult maintenance system. They are widely applied in steel, cement, coal, power, petrochemical and papermaking areas, such as the reduction gearbox of conveyor, coal mill, extruder, blender mixer and other heavy equipment industry gearbox. These oils are also suitable for marine propeller, deck winch, crane, steering gear, etc., the reducer of excavator, dragline, electric-wheeled self-dumping trucks and other equipment in open-pit coal mines. Gear Oils XD meet the performance standards of DIN 51517 Part III (2014); ISO:12925-1 Type CKC/CKD; AGMA EP 9005-EO2 (EP); AISE (US STEEL): 224; David Brown S1.53.101 and Flender Gear Boxes – REVISION 9; and IS:8406/93. The anti-wear properties of EA Gear Oils XD include resistance to oxidation, foam buildup, sludge and varnish formation. Their outstanding thermal stability reduces the formation of oxides at high temperatures. These oils have superior demulsibility and minimize emulsion formation in circulating systems which are usually subject to contamination with large quantities of water. They also have excellent seal compatibility. These properties combine to effectively protect gear system components against wear, rust and corrosion, even under severe high or low temperatures. They also sustain load carrying capacity and their unique anti-micro-pitting ability for gear sets reduces the risk of premature damage.

Product
Gear Oils XF
Base fluid
Mineral
Viscosity grade
100, 150, 220, 320, 460, 680, 1000,
Description

Gear Oils XF is a series of premium quality heavy duty gear oils designed to lubricate modern industrial gear boxes working under extreme pressure conditions. The XF grades are known to provide clean gear performance and excellent protection against micro pitting wear. These gear oils are recommended for splash or circulation lubrication of all types of enclosed gears especially for heavy loads, high speeds and high relative sliding velocities at elevated, ambient and operating temperatures in power, steel, cement and paper industries. These types of oil are recommended for the lubrication of bevel spur, helical and planetary gear boxes. Gear Oils XF have earned Siemens MD approval for Flender gear boxes Revision 15 and also conform to DIN 51517 (CLP) Part III (2014); AGMA 9005-F16 Anti scuff; AIST 224; David Brown S1.53.101 TYPE MA & E; ISO:12925-1 (CKC/CKD); GB 5903-2011 (CKD) and Fives Cincinnati EP Gear Oils performance standards. Gear XF series oils offer excellent protection against rust and corrosion, enhanced oxidation stability and resistance to foaming. The blends’ inherent friction modifying characteristic reduces the friction which in turn enhances gear efficiency and reduces power consumption. They provide excellent oxidation and thermal stability, effective resistance to micro pitting, enhanced anti-wear and extreme pressure properties. They also have excellent demulsibility and very low foaming tendency.

Product
Gear Oil SPL
Base fluid
Mineral
Viscosity grade
68, 100, 150, 220, 320, 460, 680, 1000, 1500,
Description

Gear Oil SPL is a series of high performance extreme pressure gear oils primarily designed for heavy duty gear boxes. These gear oils have extreme pressure properties along with anti-wear property to enhance the performance level. They are recommended for splash or circulation lubrication of all types of enclosed gears, especially where operating conditions involve heavy loads, high speeds and high relative sliding velocities at elevated ambient and operating temperatures in industrial and marine applications. They can also be used to lubricate other heavily loaded parts and components such as couplings, transmission screws and low speed plain and roller bearings. As indicated, they can be used in oil-mist lubrication systems too. The blends in the Divyol Gear SPL range conform to performance standards of DIN 51517-3: 2009-06, AGMA EP 9005-E02, DIN51517 PART-III (CPL) and IS:8406-1993. Gear Oil SPL oils contain chemically active additives which react with the metal of the gear teeth to form an anti-welding film between them. The blend provides enhanced gear wear protection from micro pitting. It also provides improved protection from rust and wear to bearings and other gear box internals. These qualities along with its anti-oxidant properties offer longer service life of the machines.

Product
Gear Oils SP
Base fluid
Mineral
Viscosity grade
68, 100, 150, 220, 320, 460, 680, 1000, 1500,
Description

Gear Oils SP are premium quality lubricants fortified with sulphur-phosphorous type of EP additives. These oils are recommended for the lubrication of heavy-duty enclosed gear drives with circulation or splash lubrication systems operating under heavy or shock loading up to operating temperature of 110 °C. They are also recommended for systems with plain and roller bearings, sliding surfaces, chain drives, sprockets, flexible coupling employing splash, circulation or spray lubrication systems, requiring oil to withstand extreme pressures. They are not suitable for gear systems with brass, bronze and white metal components. Gear Oils SP conform to performance standards of IS:8406/93 (Reaffirmed 2016), AGMA STANDARD 250.04/9005-D94 and Cincinnati Machine – P-63, P-76, P-77, P-74, P-59. Gear Oils SP have excellent anti-foam, anti-rust and anti-oxidation properties and thermal stability making them ideal for heavy shock loads operations. They have excellent low and high temperature resilience, providing consistent service even at temperatures up to 110 °C and may also be used for spray lubrication systems requiring extreme pressure. They also enhance high load carrying capabilities and reduce galling, scuffing and welding.

Product
Gear Oils XS
Base fluid
Mineral
Viscosity grade
150, 220, 320, 460, 680, 1000,
Description

Gear Oils XS is a series of fully synthetic heavy-duty industrial oils designed for spur, helical, bevel gear and bearing in industrial equipment as well as ships with heavy loads and under harsh environment conditions. These gear oils are especially recommended for applications that require long service life, get little maintenance or have a very difficult maintenance system. They are also suitable for reduction gearbox of conveyor, power plant, coal mill, extruder, blender mixer and other heavy equipment gearbox used in steel, cement, coal, power, petrochemical and paper industries. They serve well even when used for marine propeller, deck winch, crane, steering gear, the reducer of excavator, dragline, electric-wheeled self-dumping trucks and other equipment in open-pit coal mines. Each grade in the EA Gear Oils XS series conforms to performance standards of DIN 51517 Part III (2014); ISO 12925-1 Type CKC/ CKD; AGMA EP 9005-EO2 (EP); AISE (US STEEL): 224; David Brown S1.53.101 and FLENDER GEAR BOXES – REVISION 9. Gear Oils in the XS series have a high viscosity index which enables reliable and trouble-free operation even in harsh environmental conditions. Besides thermal stability they also have exceptional oxidation inhibition properties. Their unique anti- micro-pitting ability for gear sets reduces the risk of premature damage. Their excellent seal compatibility, next generation additives, load carrying capacity, adequate demulsibility and superior anti-rust, anti-corrosion properties add up into effective protection and therefore longer service life of the gear.

Before recommending a lubricant, inspecting and analysing the on-site equipment while it is in normal use would be ideal. Generally speaking, the American National Standards Institute (ANSI)/American Gear Manufacturers Association (AGMA) 9005-E02 standard can be used to advise an oil viscosity for your application.
